Do not use the tie-down hook(s) for towing purposes. If the tiedown hook(s) are used for towing, the tie-down hook(s) or bumper will be damaged and this could lead to serious injury.
Hyundai Tucson (LM) 2010-2015 Service Manual: Oil Pump Components and Components Location
Components
1. Reaction shaft support assembly2. Oil pump housing3. Driven gear4. Drive gear5. Oil seal6. Bushing-housing7. Reaction shaft8. Bushing-reaction shaft9. Sleeve10. Flange bolt
Oil Pump Operation Flow
1. Inhale (Oil filter)2. Inhale (Valve body)3. Outlet4. 26/B operation pressur ...
Hyundai Tucson (LM) 2010-2015 Service Manual: Specifications
Specifications
ItemSpecificationTypeElectric Power Steering SystemSteering gearTypeRack & PinionRack stroke153mm (6.02 in.) ± 1 (0.3937 in)Steering angle(Max.)Inner39.4°±1.30`Outer31.9°
Tightening Torques
ItemTightening torque (kgf.m)NmKgf.mlb-ftHub nuts88.3 ~ 107.99.0 ~ 11.065.1 ...
